PVC 3.0mm Fiber Optic Patch Cord LC UPC To LC UPC Uniboot Duplex OS2 Single Mode

PVC 3.0mm Fiber Optic Patch Cord LC UPC To LC UPC Uniboot Duplex OS2 Single Mode

MOQ: >500

Material: PVC

Brand: HRI

Delivery Time: 7-25days

Start Port: Shenzhen

Supply Ability: 1000pcs/day

View full details

Product Description

The 50/125μm OM2 multimode fiber optic cable meets RoHS compliant and is optically tested for insertion loss to ensure high quality. It is very cost-effective for network cabling in data centers, enterprise networks, telecom rooms, server farms, cloud storage networks, and any places fiber patch cables are needed

Product information

Mode Single Mode Multimode
Insertion Loss ≤ 0.30dB ≤0.20 dB ≤0.20 dB
Return Loss ≥ 50dB ≥ 60dB ≥ 30dB
Test Wavelength 1310/1550nm 850/1310nm
Durability(500 Matings) ≤0.20 dB
Operating Temperature -40℃~+60℃
Storage Temperature  -45℃~+85℃
Fire Resistant IEC 60794-2-30
Standards-Compliant ROHS,IEC and GR-326
  • The best insertion loss and return loss ensure stable signal transmission and network security. Good thermal stability, high hardness, strong environmental adaptability.

  • In the case of extreme fiber bending, the optical signal leaked to the outside of the core due to bending is retained to reduce fiber loss and print clearly.

Technical parameters:

  1. Simplex or duplex or multi fiber assemblies
  2. Riser or Plenum rated, LSZH and RoHS cables available
  3. Low insertion loss, IEC, TIA/EIA, Telcordia compliant
  4. Custom fiber optic cable lengths and jacket colors
  5. Various fiber types and wavelengths, typical 9/125 single mode, 50/125 multimode and 62.5/125 multimode
  6. 0.9 / 1.8 / 2.0 / 3.0 / mm outer diameter fiber optic cables
  7. PC, UPC, and APC polish types
  8. Good packing, competitive prices and very fast delivery
  9. 100% geometry test anc IEC cleaning test are available
  10. OEM service is available
