HRI Connect GmbH

MPO/PC, MPO/PC, Multi-mode, 8 cores, MM, 3.5 mm, LSZH

MPO/PC, MPO/PC, Multi-mode, 8 cores, MM, 3.5 mm, LSZH

MOQ: >500

Material: PE

Brand: HRI

Delivery Time: 5-15days

Start Port: Shenzhen

Supply Ability: 300pcs/day

View full details

Product Description

These multi-fiber cables from L-com offer up to 8 times the density compared to the same size SC connector. These cables connect equipment in data centers where 10 to 40Gbps ethernet connections are required and are specifically designed to work with 40G QSFP transceivers. Made with a Low Smoke Zero Halogen (LSZH) jacket, it gives off very little smoke and does not produce toxic halogen-based gasses. Type B is a Key Up to Key Up connector configuration and refers to the connector's polarity. This cable comes with alignment pins. These are also fully compatible with US Conec MTP products.

Product information

Parameters Specifications Notes
Fiber Count 8F

Comply with RoHS requirement;

Endface comply with IEC 61300-3-35

Fiber Type OS2/OM1/OM2/OM3/OM4/OM5
Test Wavelength 850nm (Multimode)
1310 & 1550nm(Single Mode)
Insertion Loss MPO/ MTP® Standard loss ≤0.75dB
Low loss ≤0.35dB
Return Loss Multimode ≥20
Single Mode ≥60 (APC)、≥50 (UPC) dB
Polarity See Polarity(Conform to ANSI/TIA-568.3-D Standard)
Mechanical Endurance  ≥500 Times
Working temperature  -20 ~+60℃

Product Features

1. Low insertion loss and high return loss
2. Excellent end-face geometry parameter
3. Special spec.available upon customer’s request.

Applicable Scope

1. Data transmission Networks
2. Image transmission Networks
3. Optical test instrument

For more information, please contact us

Email: sales@hri-connect.de

Tel: (+49) 8938 9992 58
