HRI Connect GmbH

432 Cores SC / APC Fiber Optic Jumper Cables , G652D Simplex Fiber Patch Cord

432 Cores SC / APC Fiber Optic Jumper Cables , G652D Simplex Fiber Patch Cord

MOQ: >500

Material: PVC

Brand: HRI

Delivery Time: 7-25days

Start Port: Shenzhen

Supply Ability: 500pcs/day

View full details

Product Description

Fiber Optic Pigtail is important of optical network.they have same or different connectors which are installed on the end of fiber optic cable. The Fiber Optic Pigtail series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deployment.

Product information

Mode Single-mode Multimode
Insertion Loss ≤0.2dB ≤0.2dB ≤0.2dB
Return Loss ≥50dB ≥60dB ≥35dB
Test Wavelength 1310/1550nm 850/1310nm
Durability(500 Matings) ≤0.2dB
Operating Temperature -20℃~+70℃
Storage Temperature -40℃~+85℃
Fire Resistant IEC 60794-2-30
Standards-Compliant ROHS,IEC and GR-326
  • The best insertion loss and return loss ensure stable signal transmission and network security.Good thermal stability, high hardness, strong environmental adaptability.

  • In the case of extreme fiber bending, the optical signal leaked to the outside of the core due to bending is retained to reduce fiber loss and print clearly.

Product Features

  1. Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
  2. Ferrule End-face: PC, UPC, APC
  3. Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
  4. Cable Quantity: Simplex, duplex or customized
  5. Cable Diameter: 3.0mm, 2.0mm, 0.9mm
  6. Cable Length: 1, 2, 3 meter or customized
  7. Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum

For more information, please contact us
